FURUKAWA Excavator Breakers: High-Impact Energy for Rock Drilling & Quarrying

A Manufacturer Built in the Rock Face

FRD USA is a wholly owned subsidiary of FURUKAWA ROCK DRILL CO., LTD., founded in 1875 by Ichibei Furukawa to mine and smelt copper. That starting point — a copper mine, not a factory floor — is not a footnote. It means the engineering lineage behind every FRD breaker runs directly back to hard-rock extraction, and the product decisions made over 150 years reflect what actually breaks granite without breaking the machine.

Today, Furukawa Rock Drill's hydraulic breakers contribute to global infrastructure development by offering a diverse lineup of small to ultra-large models for bedrock excavation, meeting customers' diverse needs. The FX series spans mini-excavator mounts up to extra-large units for 110-tonne carriers, with the breaker body design based on vibration mode analysis at each size class — not a single scaled template but a set of purpose-engineered structures matched to the specific dynamic loads of each carrier weight range.

What Actually Drives Performance in Quarry and Rock-Drilling Work

Quarry applications put two demands on a breaker that general demolition does not. First, abrasion: granite, basalt, and other igneous rock wear working steel, bushings, and front-head surfaces at a rate that soft concrete never approaches. Second, thru-bolt fatigue: the repeated shock loading of primary rock breaking has long plagued the breaker industry by shearing or stretching the bolts that hold front-head, cylinder, and back-head together. Both problems have shaped FRD's design direction over the past two product generations.

The answer to thru-bolt fatigue is the mono-block body. The new square mono-block body design eliminates thru-bolts, increasing durability and reducing maintenance and failure due to broken bolts. A single forged or cast housing that integrates cylinder and front-head removes the bolt-joint entirely — there is nothing to loosen, retorque, or replace between service intervals. On a quarry shift running eight to twelve hours, the maintenance saving compounds: operators stay on the rock face instead of stopping to check bolt torque every hundred hours.

The answer to abrasion is a combination of geometry and material selection. A patent-pending dust prevention system incorporates grooves to trap contaminants on the upstroke and expel them on the piston down stroke, while a cushion ring acts as a secondary trap. Keeping rock flour and silica dust away from the piston-to-bushing interface is the single most effective way to extend service life in a granite quarry — far more effective than simply specifying harder steel, because dust-induced wear is abrasive rather than compressive. For the Fx800, the engineered upper bushing surface keeps the 7.48-inch-diameter working steel aligned for greater impact and improved front-head durability even as the bushing wears through a full quarry season.

FX Series Model Range: Carrier Class and Primary Application

The table below maps the current FX series to carrier weight and the quarry or rock-drilling applications each class handles most efficiently.

Choosing the Right FX Model for Your Rock Application

The advanced hydraulic circuit provides increased flow to the valve and piston, resulting in faster cycle times, increased tool penetration and more productivity per hour than on previous models. That gain is most visible in secondary breaking — reducing oversize rocks after blasting to crusher-feed size — where cycle speed directly determines how many passes the excavator makes per shift. The Fx275 Qtv and Fx375 Qtv sit in the sweet spot for most quarry secondary-breaking tasks: large enough to fracture boulders up to two cubic metres in a single pass, light enough to run continuously on a 20–40 tonne carrier without generating excess heat in the excavator's hydraulic circuit.

For primary blast-free rock excavation — where the breaker is working directly on an undisturbed rock face — the Fx475, Fx800, and Fx1070 bring the hydraulic input power and front-head robustness that the hardest formations require. The Fx800 builds on that foundation with multiple updates and advancements to make it even more powerful and efficient, while also reducing downtime and maintenance. The anti-blow feature on the Fx800 prevents blank firing against irregular rock faces, protecting the back-head from the shock that occurs when the piston strikes with no material resistance — a failure mode that kills service life faster than any other single operating error in hard-rock quarry work.

When operated properly, breakers efficiently and effectively break up concrete and shatter rock. If not operated properly or not sized correctly for the job, the attachment can fail unexpectedly and waste precious time on a job site, or even suffer a reduced lifespan. FRD's Pro-Pak package — hose whips, mounting hardware, standard working steel, and tool kit with operating manual — ships with every large-series unit specifically to get the installation right the first time, because a mismatched flow or pressure setting in the first week of operation causes more long-term damage than the same error discovered after the first service interval.
