Glyd Ring Working Pressure &Temperature Range:Full Specification

Glyd Ring Design and Function

The Turcon Glyd Ring is a very effective and reliable low frictional seal.It is particularly suitable as a piston seal in both high and low pressure systems.Glyd  Ring  is a double-acting O-Ring energized  piston seal for dynamic applications.Glyd Ring provides low friction with no stick-slip,minimal break out force and high wear resistance.

Standard Operating Parameters

Pressure:up  to  60  MPa.

Speed:up to  15  m/s.

Frequency:up  to  5  Hz.

Temperature:-45C to  +200℃*depending  on  o-ring  material.

Media:Mineral  oil,other  media  on  request.

The O-Ring Operation Temperature is only valid in mineral hydraulic oil(except EPDM).  e.g.the  maximum  operating  speed  depends  on material  type,pressure,temperature  and gap  value.

Temperature range also dependent on medium.

Material-Specific Ranges

Turcon®materials(PTFE-based)allow operation from-45°C  to +200℃  with  appropriate energizer.For NBR energizer,typical upper limit is +100℃ to +110℃ .For  FKM  energizer,full  range  to+200℃ is  achievable. Zurcon®(polyurethane)variants may have different limits,such  as  -30℃ to+80℃ in some  cases.Bronze-filled  PTFE  slide  ring  provides  excellent  performance  in  high-pressure  hydraulic applications.

Additional Specifications

Size  Range:3 mm to 2600 mm.

Pressure  (max):60  MPa.

Speed(max):15  m/s.

Operating  Temperature:-45℃  to  +200℃ .

In some applications,working  pressure  can  reach  70  MPa with  optimized design.
