Product Overview
This premium repair seal kit is engineered for Sauer Danfoss 90-series PV90R180 and PV90L180 180cc hydraulic piston pumps. It includes all essential shaft seals, O-rings, gaskets and backup rings for full pump overhaul.
Made of imported high-quality NBR and FKM fluororubber, the kit features excellent oil resistance, temperature resistance and wear resistance. It perfectly replaces original Danfoss seals, solves common problems such as oil leakage and pressure loss, and prolongs pump service life under long-term heavy-duty operation.
Product Display
Product Specifications
Item |
Detailed Parameter |
Product Name |
Danfoss PV90R180 Hydraulic Pump Seal Kit |
Applicable Model |
PV90R180 / PV90L180 (180cc Displacement) |
Compatible Series |
Sauer Danfoss 90 Series Piston Pump |
Main Material |
Imported NBR / FKM Fluororubber + Reinforced Backup Ring |
Max Working Pressure |
42MPa |
Working Temperature |
-30°C ~ 120°C |
Kit Contents |
Shaft seal, O-rings, gaskets, backup rings, full overhaul parts |
Cross Reference OEM No. |
80020S180, 12589 |
Net Weight |
Approximately 1.6kg |
Applicable System |
Closed-loop hydraulic piston pump system |
Warranty |
12 Months |
Key Selling Points
1. 100% Exact OEM Replacement.Fully compatible with original Sauer Danfoss PV90R180 / PV90L180 piston pumps. Matches OEM part numbers 80020S180 and 12589. No modification required for direct installation.
2. Premium Imported Sealing Material.Core sealing parts adopt high-performance FKM rubber and reinforced backup rings. The material is oil-proof, corrosion-resistant and aging-resistant, working stably in temperatures from -30°C to 120°C.
3. Zero Leakage & High Pressure Durability.All components are strictly tested under 42MPa high pressure. It eliminates internal and external oil leakage, maintaining stable hydraulic pressure and consistent machine power output.
4. Complete All-in-One Repair Kit.Covers all sealing accessories needed for full pump maintenance. Complete parts reduce repair time and lower equipment operation costs.
5. Strict Factory Quality Control.Every seal kit passes air tightness, high pressure and aging tests before delivery. It meets OEM standards and ensures reliable long-term industrial performance.
6.Application Scope.Suitable for Danfoss PV90R180 hydraulic pumps on various heavy-duty equipment:
